SLICE HG
Ultra-rugged 20,000 g shock-rated data acquisition for blast, hard-target, and survivability testing.
View Product Manual
Small Size
Rugged
Versatile
Onboard
Availability
Support
FEATURES
- Size: 31.75 mm diameter × 42.52 mm, 85 grams
- Channels: 3-channel module, daisy-chain up to 12 channels
- Sampling rate: programmable up to 500k sps/channel
- Shock rating: 20,000 g
- Communication: USB interface with optional Ethernet connectivity
- Environmental: 0°C to +60°C
- Sensor support: 3- and 4-wire bridge, MEMS sensors, strain, load, voltage
Highlights
Extreme Shock Survivability
Built for tests where conventional DAQ hardware will not survive, delivers accurate and reliable data.
Embedded Field Recorder
Small enough to mount on or within the test article for close-to-source measurement in remote or destructive setups.
Compact 3-Channel Architecture
Use single units for focused measurements or daisy-chain multiple units when additional channels are required.
Trigger and Power Flexibility
Multiple sleep and trigger options, plus low-power battery back-up support, offer flexibility in demanding test scenarios.
Applications
SLICE HG is designed for extreme shock and survivability testing where measurement windows are short and data loss is not an option. Its small package, onboard memory, and very high shock tolerance support reliable acquisition in extreme field environments.
Applications include:
SOFTWARE
SLICEWare
Fast, intuitive setup, control, and data viewing software for SLICE hardware. Designed for efficient test execution with real-time visibility.
- System setup, control, and configuration
- Real-time display and monitoring
- Sensor/channel configuration
- Data recording and review
- Built-in diagnostics
- Automatic sensor assignment
SLICEWare Highlights
- Simple, fast setup workflow
- Optimized for smaller systems
Additional Software Options:
Application Programming Interface (API)
- ACCESSORIES
- APPLICATION DIAGRAMS
Thermocouple Adapters
Thermocouple Adapters offer a simple plug-n-play solution for integrating temperature data with other measurement signals when using DTS SLICE data acquisition systems. Supports Type K thermocouples. Available in two temperature range options: -100 to +400 °C; 0 to 1250 °C.
SEE ACCESSORY OPTIONS →
SLICEWare Software
SLICEWare Software is an intuitive setup, control, and data viewing software for DTS data acquisition systems. SLICEWare software is designed to provide fast, easy-to-use tools for data collection.
SEE ACCESSORY OPTIONS →
DataPRO Software
DataPRO Software is a powerful setup, control, and data viewing software for DTS acquisition systems. The intuitive user interface is designed to help test engineers create, control, and manage every aspect of a test.
SEE ACCESSORY OPTIONS →
Range Expanders
Range Expanders are an adapter cable that allow DTS data acquisition systems to safely record voltage signals exceeding the standard input range. Available in ±20 V, ±40 V, ±60 V and ±800 V ranges. Various connector options available (LEMO, Omnetics, Tajimi).
SEE ACCESSORY OPTIONS →
